X-Power electric winches are designed in the USA. We stand for unbeatable performance. Our products are based on a long history of heavy duty durable production.
- Rugged and Reliable 3-Stage Planetary Gear system for lasting performance
- High Torque 125mm Series Wound Motor For Superior Winching Power & Superior Speed at 100% Loaded Capacity .
- USA Patented Gear Housing With Duel Disk Brake Provides Ultimate Load Control and Safety.
- Large 70mm (2.75 in) Winch Drum to minimize stress on rope.
- Brake Located in Gear Housing keeps Drum cool during pulls, Avoiding excessive Heat and Rope damage.
- Fully Sealed to Keep Water and dirt out and lubrication in- IP68 Standard.
- Available in Integrated and Non-Integrated models with rotatable gear housing for a better fit to your vehicle.
- Relocatable Control pack on Non-Integrated Models.
- Remote Control can be used as Corded Remote or Wireless Remote.
- Remote Control has Led Flashlight and USB charging so it can be used any time.
- Remote Control provides Overload and Low Battery Voltage information to user.
-
>1200 times working life
Limited Lifetime Warranty For Gears.
7 Years Warranty For Electrical
Condition Apply
Technical Specification
Rated Single Line Pull : 12000Ib (5454kg)
Motor : 12V DC 7.0 HP Series Wound
Gear Train : 3 -Stage Planetary
Gear Ratio : 242 :1
Free spool clutch :Locking Ring Gear
Brake : Automatic Duel Disk
Drum (Dia .XL) : 2.75" x 8.8" (70mm X 223mm)
Clevis Hook : 3/8", Clevis with Spring -Loaded Safety Latch
Rope Size : 0.375" x 79'FEET(24M)
Overall Dimensions : 554mm x 164mm x247mm
Weight : 29.6kg
